What is the SAE-AS-81531 mark permanence test for wire sleeves?

SAE-AS-81531 is a rigorous military and aerospace test that evaluates print permanence on heat-shrink sleeves. A hard rubber eraser with a 1 lb load is rubbed across the printed text 20 times, followed by manual strokes. The text must remain completely legible with no flaking or erasure.

Which Brady materials are certified for Skydrol and aviation hydraulic fluid resistance?

Brady B-342 PermaSleeve (when printed with Series R6600 thermal transfer ribbon) and Brady B-7642 Diesel-Resistant polyolefin are certified to survive continuous exposure to Skydrol, aviation fuels (JP-8, Jet A), and hydraulic fluids.

Home GuidesMilitary & Aerospace Wire Standards

Defense & Avionics Quality Reference

Military & Aerospace Wire Marking Standards: SAE-AS-81531 & MIL-STD-202

In defense avionics, missile guidance systems, and commercial aircraft harnesses, wire marker failure is never an option. Review the testing methodologies behind SAE-AS-81531 mark permanence, MIL-STD-202 solvent resistance, and certified Brady heat-shrink materials.

SAE AS-81531 and MIL-STD-202G Method 215 Wire Marker Testing

Figure 1: Aerospace heat-shrink wire marker sleeve after 50-cycle mechanical brush rub solvent test with MIL-STD-202G fluid immersion.PermaSleeve® B-342 / B-7642

1. Core Aerospace & Military Wire Identification Standards

The following four industry standards govern physical sleeve performance, flammability, and print permanence in extreme mission-critical environments:

SAE-AS-81531 (formerly MIL-M-81531)

Active Defense Standard

Marking of Electrical Insulating Materials

Test Protocol:

Printed sleeve subjected to 20 eraser rubs with 1 lb (4.4 N) normal load, followed by 30 double strokes of finger rubbing.

Acceptance Rule:

Print legend must remain completely legible with zero loss of character definition.

Certified Brady Materials: B-342 (with R4300 / R6600), B-7642, B-7641

MIL-STD-202G Method 215K

Active Defense Standard

Resistance to Solvents

Test Protocol:

Sleeves immersed in aggressive solvents (IPA/mineral spirits, terpene defluxer, aqueous saponifiers) followed by mechanical brush rubs.

Acceptance Rule:

Zero illegibility, smearing, or dissolution of printed barcode/text.

Certified Brady Materials: B-342, B-7642, B-7646

SAE-AMS-DTL-23053/5 Class 1 & 3

Active Defense Standard

Insulation Sleeving, Electrical, Heat Shrinkable

Test Protocol:

Evaluates dielectric breakdown (600V+), flammability burn duration, tensile strength, and heat aging at 175°C.

Acceptance Rule:

Meets flame retardant UL224 requirements with self-extinguishing in < 15 seconds.

Certified Brady Materials: B-342 PermaSleeve Polyolefin

EN 45545-2 (R22 / R23 HL3)

Active Defense Standard

European Railway Rolling Stock Fire Safety

Test Protocol:

Measures smoke toxicity (CIT), optical smoke density (Ds max), and oxygen index (OI) in mass transit fire scenarios.

Acceptance Rule:

Zero halogen emissions, low toxic gas release, Highest Hazard Level 3 (HL3).

Certified Brady Materials: Brady B-7642 Halogen-Free Sleeve

2. Recommended Military-Spec Brady Wire Sleeves

Brady B-3423:1 Shrink Ratio

PermaSleeve® Military-Grade Heat-Shrink Polyolefin

Tested to SAE-AS-81531 and MIL-STD-202G Method 215K. Temperature range from -55°C to +135°C (-67°F to 275°F).

View 1,620 B-342 SKUs & Sizes

Brady B-7642Zero Halogen HL3

Halogen-Free Low-Smoke Mass Transit Wire Sleeves

Complies with EN 45545-2 (R22/R23 HL3) and NF F 16-101 for European railway rolling stock and closed-air aerospace cabins.

View 540 B-7642 SKUs & Specs
