Heat-Shrink Ratio Explained: What 2:1 vs. 3:1 Actually Buys You

The ratio on a heat-shrink spec is a working window, not a marketing number: it defines the largest thing the sleeve slides over and the smallest wire it still grips. Get the window wrong and the sleeve either never clears the connector or never stops spinning on the wire. Two minutes of recovery math prevents both.

Polyolefin heat-shrink wire marking sleeves before and after recovery, showing the diameter reduction the shrink ratio defines

Figure 1: Supplied vs. recovered — the ratio is the span between these two diameters.MIL-DTL-23053 sleeving class

1. Recovery Math by Supplied Size

Recovered diameter = supplied ÷ ratio. The two rules that use this table: supplied Ø clears the largest pass-over (connector included), recovered Ø is smaller than the insulation OD so the sleeve grips:

Supplied Ø	3:1 Recovers To	2:1 Recovers To	Typical Fit
3/32″ (0.094)	≈ 0.031″	≈ 0.047″	18 AWG class
1/8″ (0.125)	≈ 0.042″	≈ 0.063″	16–14 AWG
3/16″ (0.187)	≈ 0.062″	≈ 0.094″	12 AWG, fiber patch
1/4″ (0.250)	≈ 0.083″	≈ 0.125″	10 AWG
3/8″ (0.375)	≈ 0.125″	≈ 0.187″	8 AWG, Cat5e/6
1/2″ (0.500)	≈ 0.167″	≈ 0.250″	6–4 AWG, Cat6A
3/4″ (0.750)	≈ 0.250″	≈ 0.375″	2–1/0 AWG
1.0″	≈ 0.333″	≈ 0.500″	2/0 AWG class

Worked example: marking 16 AWG leads (≈ 0.08" insulation OD) already fitted with 0.25" ring terminals. A 1/8" sleeve grips the wire but never clears the terminal; a 3/8" 2:1 clears the terminal but recovers to 0.187" — loose. The 3/8" 3:1 clears the terminal and recovers to 0.125", snug on the wire. That asymmetry is the entire case for 3:1 in terminated work.

2. The Two Printable Families

B-342 PermaSleeve — 3:1

Irradiated polyolefin, -55°C to +135°C, UL 224 recognized, 1,516 catalog SKUs across diameters and formats. The default marking sleeve for panels, harnesses, and mil/aero work — pairs with R4300 or R6600 ribbons per the compatibility chart.

Explore B-342 sizes

B-7642 PermaSleeve LSZH — 2:1

Low-smoke zero-halogen polyolefin, UL 224 file E146526, 949 SKUs. Specified where combustion toxicity rules govern — rail vehicles and enclosed transit per EN 45545-2 — accepting the shallower 2:1 window as the price of the fire-safety chemistry.

Explore B-7642 sizes

Recovery technique in three lines

Heat gun, not flame. Keep the gun moving and rotate the wire so the sleeve recovers evenly — uneven heat is how printed legends distort. Stop at snug and glossy; continued heating past full recovery only ages the sleeve and risks the legend.

Sizing sleeves for a specific gauge list?

The AWG sizing chart pairs every common gauge and cable type with its wrap height and supplied sleeve diameter — the chart this math generates.

Open the AWG Sizing Chart
